Our company has developed and customized many kinds of electric bridges which have been realized by stripe line and waveguide. Output phase characteristics could be classified as two forms including 90° and 180°, with a frequency coverage of DC~40GHz. The connection mode includes leading line, coaxial connector and waveguide.
Electrical Performance Indicators of Typical Products
|
No. |
Frequency Range（GHz） |
Phase Characteristics（°） |
Insertion Loss (dB) |
Isolation (dB) |
Amplitude Unbalance (dB) |
Phase Unbalance （°） |
Standing Wave |
Power Handling Capacity (W) |
Connection Type |
|
1 |
0.75~1.5 |
180 |
0.5 |
22 |
0.5 |
10 |
1.2 |
50 |
SMA |
|
2 |
1~2 |
180 |
0.6 |
22 |
0.5 |
10 |
1.2 |
50 |
SMA |
|
3 |
2~4 |
180 |
0.8 |
20 |
0.7 |
10 |
1.3 |
50 |
SMA |
|
4 |
2~18 |
180 |
1.6 |
16 |
1.0 |
12 |
1.5 |
50 |
SMA |
|
5 |
4~8 |
180 |
1.4 |
20 |
0.8 |
10 |
1.35 |
50 |
SMA |
|
6 |
4~18 |
180 |
1.8 |
16 |
1.0 |
12 |
1.6 |
50 |
SMA |
|
7 |
5~26.5 |
180 |
2.0 |
14 |
1.0 |
10 |
1.6 |
50 |
2.92 |
|
8 |
26.5~40 |
180 |
3.5 |
12 |
1.0 |
12 |
1.7 |
50 |
2.92 |
|
9 |
0.25~0.5 |
90 |
0.3 |
22 |
0.6 |
2 |
1.2 |
50 |
SMA |
|
10 |
0.5~1.25 |
90 |
0.35 |
18 |
0.65 |
5 |
1.3 |
200 |
引线 |
|
11 |
0.5~1.25 |
90 |
0.35 |
18 |
0.65 |
5 |
1.3 |
400 |
引线 |
|
12 |
0.75~1.5 |
90 |
0.3 |
22 |
0.5 |
2 |
1.3 |
50 |
SMA |
|
13 |
0.8~2.5 |
90 |
0.5 |
18 |
0.6 |
5 |
1.3 |
200 |
引线 |
|
14 |
1~2 |
90 |
0.3 |
22 |
0.5 |
2 |
1.15 |
50 |
SMA |
|
15 |
2~4 |
90 |
0.4 |
20 |
0.6 |
5 |
1.35 |
50 |
SMA |
|
16 |
2~18 |
90 |
1.3 |
16 |
0.8 |
10 |
1.4 |
50 |
SMA |
|
17 |
4~8 |
90 |
0.5 |
20 |
0.6 |
5 |
1.35 |
50 |
SMA |
|
18 |
6~18 |
90 |
1.0 |
16 |
0.7 |
10 |
1.6 |
50 |
SMA |
|
19 |
10~26.5 |
90 |
1.7 |
15 |
0.7 |
7 |
1.6 |
20 |
2.92 |
|
20 |
10~40 |
90 |
2.0 |
12 |
0.7 |
10 |
1.8 |
20 |
2.92 |
